PIXX 1417 is a flat-panel digital x-ray detector with image coverage of 14″ by 17″ for portable application with features not found on any other image device. PIXX 1417 is equipped with premium Gadox scintillator which allows high X-ray sensitivity and high image quality. Thanks to 2nd generation AED technology which makes continuous and stable image acquisition without any loss of x-ray signal. On-board storage and Mobile Viewer allow users to use DR detector as like CR imaging plate. The detector provides other features that you love.


High Image Quality

-High SNR and Low Noise at lower dose

Faster Image Acquisition

– less than 3-5 second

AED Plus

– Second generation of continuous @ accurate AED provides faster and efficient image acquisition

Stand-alone use

– Without workstation, detector works with x-ray source in portable & mobile environment

On-board Storage

– Protect any data loss by saving up to 150 image on the detector

Web Viewer for Mobile Phone

– Instant Viewer form any personal mobile devices

One-pieces Carbon Body

– Full carbon fiber housing allows light and durable detector

OLED Display for Status

– OLED window helps user to check the status of detector



  • High Image Quality
  • Long Battery Life
  • On Board Storage
  • Mobile Viewing
  • OLED Window
  • Whole Carbon Body
  • AED Plus Technology
  • HDMI Data Cable
Product Options
  • Wired: Standard (HDMI type) Data Link Cable
  • Wireless: High Speed WI-FI, approx, 6 hours of battery life
  • Application: General Radiography
  • Sensor: a-Si TFT array Flat Panel Detector
  • Conversion Screen: Csl / GOS
  • Image Size: 14 x 17 inch (350mm x 427.25mm)
  • Sensor Pixel: 2,560 x 3,072 (7.8M pixels)
  • Pixel Size : 140 µm
  • Spatial Resolution: 3.6 lp/mm
  • Image Data: 14 bit / 16 bit
  • Trigger Mode: AED (Automatic Exposure Detection), Manual Trigger
  • Calibration Mode: ACC (Auto Calibration Control), Manual Calibration
  • Data Transfer Time: Less than 1 sec
  • Capture Cycle Time: 3-5 sec. approx
  • Wired Interface: Gigabit Ethernet
  • Voltage: AC 100 ~ 240 V, 50 / 60 Hz | DC18V 3.5A
  • Wireless Standard: IEEE 802.11ac
  • Battery Type: Lithium Ion Polymer Battery
  • Dimensions (W x L x T): 385mm x 460mm x 15mm
  • Weight: 2.4Kg (5.2 lb), 2.8Kg (6.1 lb, with battery)
